The CM-2 is a high-precision, multi-constellation, and multi-frequency GNSS receiver supporting both RTK and PPK modes. It integrates high-speed USB data access, a high-brightness OLED display, dual-antenna heading support, and industrial-grade anti-interference technology, making it the ideal core component for autonomous driving, UAV surveying, and high-precision robotic positioning.
Key Features:
- Multi-Constellation Tracking: Supports GPS, BDS, and GLONASS (L1, L2, L5) for faster signal acquisition and stability in challenging environments.
- RTK/PPK Dual Support: Compatible with both Real-Time Kinematic and Post-Processed Kinematic technologies for centimeter-level accuracy.
- Low Power & Wide Voltage: Supports 6V-30V input with only 0.8W power consumption, ideal for integration into mobile platforms.
- Dual-Antenna Heading: Dual antenna interfaces provide high-precision heading output and superior resistance to magnetic interference.
- Intuitive Interaction: Built-in OLED display for real-time status updates, 64GB internal flash, and high-speed USB for easy data management.
Technical Specifications:
- Tracking Channels: 1048 Channels
- GNSS Support: BDS: B1/B2/B3; GPS: L1/L2/L5; GLONASS: L1/L2
- Positioning Accuracy: Horizontal: 0.8m + 1ppm; Vertical: 1.5m + 1ppm
- Core Hardware: ARM 32-bit core processor with 64GB embedded flash memory
- Power & Voltage: Power consumption ≤ 0.8W; Input voltage range 6V to 30V
- Update Rate: Default 5Hz, supports up to 20Hz maximum update rate
- Interface Configuration: Micro USB data port, dual MMCX antenna connectors, 8-pin multi-function expansion port
- Physical Specs: Dimensions 52.35mm x 36.6mm x 15.1mm; Weight 32.9g (excluding antenna)
Application Fields:
The CM-2 is widely used in industries requiring extreme spatial precision, including: autonomous driving path planning, professional UAV surveying and mapping, industrial robot outdoor positioning, GIS data acquisition, and automated navigation for precision agriculture.
